Sound Generator
Max. Polyphony
64 voices
Tones
Piano: 10 tones
E.Piano: 10 tones
Organ: 10 tones
Other: 10 tones (including a drum set)
GM2: 256 tones (Settings can be changed only through the Roland Piano App.)
Master Tuning
415.3 Hz--466.2 Hz (adjustable in increments of 0.1 Hz)
Transpose
-6--+5 (in semitones)
Effects
Ambience (0--10, 5 types)
Brilliance (-10--+10)
Only for Organ Tones: Rotary Speaker Effect
Piano Designer (Settings can be changed only through the Roland Piano App.)
Lid
Damper Resonance
Single Note Tuning
Single Note Volume
Temperament
Temperament Key
Keyboard
Keyboard
88 keys (Ivory Feel and Box-shape Keys with velocity)
Touch Sensitivity
Key Touch: 5 types, fixed touch
Sound System
Speakers
Speakers: 12 x 6 cm (4-3/4 x 2-3/8 inches) x 2
Rated Power Output
6 W x 2
Bluetooth
Bluetooth Ver 5.0
Profile: A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)
CODEC: SBC (Supports SCMS-T content protection)
Compatible Android / iOS Apps (Roland)
Compatible Android / iOS Apps (Roland)
Roland Piano App
* Support for the app may be terminated without prior notice.
Recorder
Standard MIDI Files
Standard MIDI Files (Format 0)
Song: 1
Part: 1
Recording capacity per song: approx. 500 KB
Internal Songs
Internal Songs
10 songs
Convenient Functions
Convenient Functions
Metronome (adjustable Tempo/Beat/Volume, with Rhythm Pattern: 13 patterns)
Transpose (Keyboard: in semitones)
Dual
Split (Settings can be changed only through the Roland Piano App. Split point adjustable)
Twin Piano
Speaker volume and Headphones volume automatically select function
Speaker Auto Mute
Auto Off
Other
Connectors
DC In jack
Pedal jack (Capable of half pedal detection when optional pedal DP-10 connected)
USB Computer port: USB Type-C(R) (Class Compliant for Audio and MIDI)
Phones/Output jack: Stereo miniature phone type
Power Supply
AC adaptor or Alkaline battery (AA, LR6) / Ni-MH battery (AA, HR6) x 8
* Carbon-zinc batteries cannot be used
Current draw
400 mA (When using the included AC adaptor)
Power consumption when in OFF mode (when the power automatically turns off)
0.2 W
Battery Life for Continuous Use
Ni-MH batteries (AA, HR6): Approximately 7 hours (When using batteries having a capacity of 1,900 mAh.)
Alkaline batteries (AA, LR6): Approximately 6 hours
* This figure will vary depending on the actual conditions of use.
Accessories
Music Rest
Quick Start
List of Operations
Leaflet “USING THE UNIT SAFELY”
AC Adaptor
Power Cord
Option (Sold separately)
Keyboard Stand: KS-11Z, KS-13
Damper Pedal: DP-2 (Pedal switch), DP-10 (Capable of half pedal)
Size (Without music rest)
Width
1,280 mm
50-7/16 inches
Depth
276 mm
10-7/8 inches
Height
84 mm
3-5/16 inches
Size (With music rest)
Width
1,280 mm
50-7/16 inches
Depth
309 mm
12-3/16 inches
Height
245 mm
9-11/16 inches
Weight (excluding AC adaptor and music rest)
Weight
5.8 kg
12 lbs 13 oz
